I40F _featured

I40F HiReach (46KV)

Working Height:
45' / 13,7 m

Working Side Reach:
30' / 9,1 m

Platform Capacity:
600 lbs / 272 kg

Platform Type:
Insulated Top-Mount

Jib Winch Capacity:
500 lbs / 227 kg

Powered Boom Sections:
2

Overall Height:
11’8” / 3,5 m

Unit Weight (Bare):
16,800 lbs / 7620 kg

Outrigger Spread Front:
12' / 3,6 m


View Product Details
G450f_featured

G40F HiReach

Working Height:
45' / 13,7 m

Working Side Reach:
30' / 9,1 m

Platform Capacity:
1,000 lbs / 454 kg

Platform Type:
Top-Mount

Jib Winch Capacity:
1,000 lbs / 454 kg

Powered Boom Sections:
2

Overall Height:
11’3” / 3,4 m

Unit Weight (Bare):
10,000 lbs / 4536 kg

Outrigger Spread Front:
12'6" / 3,8 m


View Product Details
M43_featured

M43R HiReach

Working Height:
48' / 14,6 m

Working Side Reach:
36' / 11 m

Platform Capacity:
500 lbs / 227 kg

Platform Type:
EZR Removable

Jib Winch Capacity:
500 lbs / 227 kg

Powered Boom Sections:
2

Overall Height:
11’7” / 3,5 m

Unit Weight (Bare):
8,400 lbs / 3810 kg

Outrigger Spread Front:
8' / 2,4 m


View Product Details
S50R _featured

S50R SkyWalk

Working Height:
55' / 16,7 m

Working Side Reach:
39' / 11,9 m

Platform Capacity:
900 lbs / 408 kg

Platform Type:
SkyWalk

Jib Winch Capacity:
500 lbs / 227 kg

Powered Boom Sections:
3

Overall Height:
13’1” / 4 m

Unit Weight (Bare):
13,500 lbs / 6123 kg

Outrigger Spread Front:
12' / 3,6 m


View Product Details
OLYMPUS DIGITAL CAMERA

G50F HiReach

Working Height:
55' / 16,7 m

Working Side Reach:
39' / 11,9 m

Platform Capacity:
600 lbs / 272 kg

Platform Type:
Top-Mount

Jib Winch Capacity:
1,000 lbs / 454 kg

Powered Boom Sections:
3

Overall Height:
11’4” / 3,4 m

Unit Weight (Bare):
11,000 lbs / 4989 kg

Outrigger Spread Front:
12'6" / 3,8 m


View Product Details
I50F_featured

I50F HiReach (46KV)

Working Height:
55' / 16,7 m

Working Side Reach:
39' / 11,5 m

Platform Capacity:
600 lbs / 272 kg

Platform Type:
Insulated Top-Mount

Jib Winch Capacity:
500 lbs / 227 kg

Powered Boom Sections:
3

Overall Height:
11’6” / 3,4 m

Unit Weight (Bare):
11,500 lbs / 5216 kg

Outrigger Spread Front:
12'6" / 3,8 m


View Product Details
S50F_featured

S50F SkyWalk

Working Height:
55' / 16,7 m

Working Side Reach:
37' / 11,3 m

Platform Capacity:
900 lbs / 408 kg

Platform Type:
SkyWalk

Jib Winch Capacity:
500 lbs / 227 kg

Powered Boom Sections:
3

Overall Height:
11’9”/3,58 m

Unit Weight (Bare):
15,500 lbs/7031 kg

Outrigger Spread Front:
18' / 5,5 m


View Product Details
L55R_featured

L55R HiReach

Working Height:
57' / 17,4 m

Working Side Reach:
51' / 15,5 m

Platform Capacity:
500 lbs / 227 kg

Platform Type:
EZR Removable

Jib Winch Capacity:
500 lbs / 227 kg

Powered Boom Sections:
3

Overall Height:
11’8”/3,5m

Unit Weight (Bare):
12,000 lbs/5443 kg

Outrigger Spread Front:
Contact Factory


View Product Details
H55R featured

H55F HiReach

Working Height:
60' / 18,3 m

Working Side Reach:
42' / 12,8 m

Platform Capacity:
600 lbs / 272 kg

Platform Type:
Top-Mount

Jib Winch Capacity:
1,000 lbs / 454 kg

Powered Boom Sections:
3

Overall Height:
11’3”/3,4 m

Unit Weight (Bare):
15,500 lbs/7031 kg

Outrigger Spread Front:
18' / 5,5 m


View Product Details
L60_featured

L60R HiReach

Working Height:
62' / 18,9 m

Working Side Reach:
56' / 17 m

Platform Capacity:
500 lbs / 227 kg

Platform Type:
EZR Removable

Jib Winch Capacity:
500 lbs / 227 kg

Powered Boom Sections:
3

Overall Height:
12’0” / 3,6 m

Unit Weight (Bare):
13,500 lbs / 6123 kg

Outrigger Spread Front:
12' / 3,6 m


View Product Details
V60_featured

V60F HiReach

Working Height:
63' / 19,2 m

Working Side Reach:
38' / 11,5 m

Platform Capacity:
500 lbs / 227 kg

Platform Type:
Top-Mount

Jib Winch Capacity:
500 lbs / 227 kg

Powered Boom Sections:
3

Overall Height:
11’3” / 3,4 m

Unit Weight (Bare):
7,760 lbs / 3520 kg

Outrigger Spread Front:
8' / 2,4 m


View Product Details
OLYMPUS DIGITAL CAMERA

I60F HiReach (46KV)

Working Height:
65' / 19,8 m

Working Side Reach:
46' / 14 m

Platform Capacity:
600 lbs / 272 kg

Platform Type:
Insulated Top-Mount

Jib Winch Capacity:
46kV Category C

Powered Boom Sections:
3

Overall Height:
11’5” / 3,4 m

Unit Weight (Bare):
16,800 lbs / 7620 kg

Outrigger Spread Front:
18' / 5,5 m


View Product Details
H60F_featured

H60F HiReach

Working Height:
65' / 19,8 m

Working Side Reach:
46' / 14 m

Platform Capacity:
600 lbs / 272 kg

Platform Type:
Top-Mount

Jib Winch Capacity:
1,000 lbs / 454 kg

Powered Boom Sections:
3

Overall Height:
11’3”/3,4 m

Unit Weight (Bare):
16,500 lbs/7484 kg

Outrigger Spread Front:
18' / 5,5 m


View Product Details
H70R_featured

H70R HiReach

Working Height:
70' / 21,3 m

Working Side Reach:
62' / 18,9 m

Platform Capacity:
500 lbs / 227 kg

Platform Type:
EZR Removable

Jib Winch Capacity:
500 lbs / 227 kg

Powered Boom Sections:
3

Overall Height:
12’1” / 3,7m

Unit Weight (Bare):
17,600 lbs / 7983 kg

Outrigger Spread Front:
12' / 3,6 m


View Product Details
G7R HiReach from Rear

G72R HiReach

Working Height:
72' / 22 m

Working Side Reach:
63' / 19 m

Platform Capacity:
500 lbs / 227 kg

Platform Type:
EZR Removable

Jib Winch Capacity:
500 lbs / 227 kg

Powered Boom Sections:
4

Overall Height:
12’3” / 3,7m

Unit Weight (Bare):
18,000 lbs / 8165 kg

Outrigger Spread Front:
12' / 3,6 m


View Product Details
H70Ffeatured

H70F HiReach

Working Height:
75' / 22,9 m

Working Side Reach:
56' / 17 m

Platform Capacity:
600 lbs / 272 kg

Platform Type:
Top-Mount

Jib Winch Capacity:
1,000 lbs / 454 kg

Powered Boom Sections:
3

Overall Height:
11’4” / 3,45 m

Unit Weight (Bare):
17,600 lbs / 7983 kg

Outrigger Spread Front:
18' / 5,5 m


View Product Details
I70F_featured

I70F HiReach (46KV)

Working Height:
75' / 22,9 m

Working Side Reach:
56' / 17,1 m

Platform Capacity:
600 lbs / 272 kg

Platform Type:
Insulated Top-Mount

Jib Winch Capacity:
46KV Category C

Powered Boom Sections:
4

Overall Height:
11’5” / 3,4 m

Unit Weight (Bare):
17,600 lbs / 7983 kg

Outrigger Spread Front:
18' / 5,4 m


View Product Details
S70R_featured

S70R SkyWalk

Working Height:
75' / 22,9 m

Working Side Reach:
65' / 19,8 m

Platform Capacity:
900 lbs / 408 kg

Platform Type:
SkyWalk

Jib Winch Capacity:
500 lbs / 227 kg

Powered Boom Sections:
3

Overall Height:
13’6” / 4,1 m

Unit Weight (Bare):
21,000 lbs / 9525 kg

Outrigger Spread Front:
18' / 5,5 m


View Product Details
Elliott G72F HiReach

G72F HiReach

Working Height:
77' / 23,5 m

Working Side Reach:
61' / 18,6 m

Platform Capacity:
600 lbs / 272 kg

Platform Type:
Top-Mount

Jib Winch Capacity:
1,000 lbs / 454 kg

Overall Height:
11'10" / 3,4 m

Unit Weight (Bare):
17,200 lbs / 7802 kg

Outrigger Spread Front:
18' / 5,5 m


View Product Details
G85R_featured

G85R HiReach

Working Height:
85' / 25,9 m

Working Side Reach:
61' / 18,6 m

Platform Capacity:
500 lbs / 227 kg

Platform Type:
EZR Removable

Jib Winch Capacity:
500 lbs / 227 kg

Powered Boom Sections:
4

Overall Height:
12’2” / 3,7m

Unit Weight (Bare):
18,000 lbs / 8165 kg

Outrigger Spread Front:
12' / 3,6 m


View Product Details
M85R_featured

M85 HiReach

Working Height:
87' / 26,5 m

Working Side Reach:
74' / 22,5 m

Platform Capacity:
750 lbs / 340 kg

Platform Type:
End-Hung

Jib Winch Capacity:
500 lbs/227 kg

Powered Boom Sections:
3

Overall Height:
13’ / 3,9 m

Unit Weight (Bare):
13,500 lbs / 6123 kg

Outrigger Spread Front:
12' / 3,6 m


View Product Details
G85F featured

G85F HiReach

Working Height:
90' / 27,4 m

Working Side Reach:
58' / 17,7 m

Platform Capacity:
600 lbs / 272 kg

Platform Type:
Top-Mount

Jib Winch Capacity:
1,000 lbs / 454 kg

Powered Boom Sections:
4

Overall Height:
11’6” / 3,5 m

Unit Weight (Bare):
18,000 lbs / 8165 kg

Outrigger Spread Front:
18' / 5,5 m


View Product Details
I85F_featured

I85F HiReach (46KV)

Working Height:
90' / 27,4 m

Working Side Reach:
59' / 17,9 m

Platform Capacity:
600 lbs / 272 kg

Platform Type:
Insulated Top-Mount

Jib Winch Capacity:
46KV Category C

Powered Boom Sections:
4

Overall Height:
11’7” / 3,5 m

Unit Weight (Bare):
18,500 lbs / 8391 kg

Outrigger Spread Front:
18' / 5,4 m


View Product Details
H90R_featured

H90R HiReach

Working Height:
90' / 27,4 m

Working Side Reach:
61' / 18,6 m

Platform Capacity:
500 lbs / 227 kg

Platform Type:
EZR Removable

Jib Winch Capacity:
500 lbs / 227 kg

Powered Boom Sections:
4

Overall Height:
13’2” / 4 m

Unit Weight (Bare):
21,000 lbs / 9525 kg

Outrigger Spread Front:
12' / 3,7 m


View Product Details
H90F_featured

H90F HiReach

Working Height:
95' / 29 m

Working Side Reach:
59' / 18 m

Platform Capacity:
600 lbs / 272 kg

Platform Type:
Top Mount

Jib Winch Capacity:
1,000 lbs / 454 kg

Powered Boom Sections:
4

Overall Height:
11’10” / 3,6 m

Unit Weight (Bare):
21,000 lbs / 9525 kg

Outrigger Spread Front:
18' / 5,5 m


View Product Details
H110R_featured

H110R HiReach

Working Height:
110' / 33,5 m

Working Side Reach:
84' / 25,6 m

Platform Capacity:
500 lbs / 227 kg

Platform Type:
EZR Removable

Jib Winch Capacity:
500 lbs / 227 kg

Powered Boom Sections:
5

Overall Height:
13’5” / 4 m

Unit Weight (Bare):
27,500 lbs / 12 474 kg

Outrigger Spread Front:
18' / 5,5 m


View Product Details
H110F_featured

H110F HiReach

Working Height:
115' / 35 m

Working Side Reach:
84' / 25,6 m

Platform Capacity:
600 lbs / 272 kg

Platform Type:
Top Mount

Jib Winch Capacity:
1,000 lbs/454 kg

Powered Boom Sections:
5

Overall Height:
13’2” / 4 m

Unit Weight (Bare):
27,500 lbs / 12 474 kg

Outrigger Spread Front:
22' / 6,7 m


View Product Details
L115R_featured

L115 HiReach

Working Height:
115' / 35 m

Working Side Reach:
80' / 24,4 m

Platform Capacity:
600 lbs / 272 kg

Platform Type:
EZR Removable

Jib Winch Capacity:
N/A

Powered Boom Sections:
4

Overall Height:
12’6” / 3,8 m

Unit Weight (Bare):
30,400 lb / 13 789 kg

Outrigger Spread Front:
20' / 6,1 m


View Product Details
E120_featured

E120 E-Line

Working Height:
120' / 36,6 m

Working Side Reach:
80' / 24,4 m

Platform Capacity:
600 lbs / 272 kg

Platform Type:
End-Hung

Jib Winch Capacity:
1,500 lbs/680 kg

Powered Boom Sections:
4

Overall Height:
13’2” / 4,1 m

Unit Weight (Bare):
28,500 lbs / 12 927 kg

Outrigger Spread Front:
20' / 6,1 m


View Product Details
L140_featured

L140 HiReach

Working Height:
140' / 42,6 m

Working Side Reach:
80' / 24,4 m

Platform Capacity:
600 lbs / 272 kg

Platform Type:
EZR Removable

Jib Winch Capacity:
N/A

Powered Boom Sections:
5

Overall Height:
12’6” / 3,8 m

Unit Weight (Bare):
30,000 lbs / 13 608 kg

Outrigger Spread Front:
20' / 6,1 m


View Product Details
Elliott E145 E-Line telescopic aerial work platform and bucket truck

E145 E-Line

Working Height:
145' / 44,2 m

Working Side Reach:
80' / 24,4 m

Platform Capacity:
1,200 lbs / 544 kg

Platform Type:
Yoke-Mount

Jib Winch Capacity:
N/A

Powered Boom Sections:
5

Overall Height:
12'11" / 3,9 m

Unit Weight (Bare):
Contact Factory

Outrigger Spread Front:
21'2" / 6,4 m


View Product Details
E160_featured

E160 E-Line

Working Height:
215' / 65,5 m

Working Side Reach:
90' / 27,4 m

Platform Capacity:
1,200 lbs / 544 kg

Platform Type:
Yoke-Mount

Jib Winch Capacity:
N/A

Powered Boom Sections:
5

Overall Height:
13'1" / 4 m

Unit Weight (Bare):
Contact Factory

Outrigger Spread Front:
21'2" / 6,4 m


View Product Details
BT1039_featured

1039 BoomTruck

Lifting Capacity:
20,000 lbs / 9072 kg

Maximum Vertical Reach:
49' / 15 m

Boom Length:
39’ / 11,9 m

Winch Bare Drum Pull:
12,800 lbs / 5806 kg

Overall Height:
13'1" / 4 m

Operator Controls:
Dual Standup

Unit Weight (Bare):
12,740 lbs / 5779 kg

Outrigger Spread Front:
17’7” / 5,3 m


View Product Details
BT1047_featured

1047 BoomTruck

Lifting Capacity:
20,000 lbs / 9072 kg

Maximum Vertical Reach:
57' / 17 m

Boom Length:
47’ / 14,3 m

Winch Bare Drum Pull:
12,800 lbs / 5806 kg

Overall Height:
13'2" / 4 m

Operator Controls:
Dual Standup

Unit Weight (Bare):
13,065 lbs / 5 926 kg

Outrigger Spread Front:
17'7” / 5,3 m


View Product Details
BT1056_featured

1056 BoomTruck

Lifting Capacity:
20,000 lbs / 9072 kg

Maximum Vertical Reach:
96' / 29,2 m

Boom Length:
56’ / 17,1 m

Winch Bare Drum Pull:
12,800 lbs / 5806 kg

Overall Height:
13'2" / 4 m

Operator Controls:
Dual Standup

Unit Weight (Bare):
13,390 lbs / 6074 kg

Outrigger Spread Front:
17’7” / 5,3 m


View Product Details
BT1560_featured

1560 BoomTruck

Lifting Capacity:
30,000 lbs / 13 608 kg

Maximum Vertical Reach:
90' / 27,4 m

Boom Length:
60’ / 18,3 m

Winch Bare Drum Pull:
12,800 lbs / 5806 kg

Overall Height:
12'11" / 3,9 m

Operator Controls:
Dual Standup

Unit Weight (Bare):
14,825 lbs / 6725 kg

Outrigger Spread Front:
20’10” / 6,3 m


View Product Details
BT1838_featured

1838 BoomTruck

Lifting Capacity:
36,000 lbs / 16 329 kg

Maximum Vertical Reach:
48' / 14,6 m

Boom Length:
38’ / 11,6 m

Winch Bare Drum Pull:
12,800 lbs / 5806 kg

Overall Height:
13'4" / 4,1 m

Operator Controls:
Dual Standup

Unit Weight (Bare):
13,540 lbs / 6142 kg

Outrigger Spread Front:
20’10” / 6,3 m


View Product Details
Elliott 18 ton 1860 tractor mount boom truck crane

1860 BoomTruck

Lifting Capacity:
36,000 lbs / 16 329 kg

Maximum Vertical Reach:
90' / 27,4 m

Boom Length:
60’ / 18,3 m

Winch Bare Drum Pull:
12,800 lbs / 5806 kg

Overall Height:
12'11" / 3,9 m

Operator Controls:
Dual Standup

Unit Weight (Bare):
14,845 lbs / 6734 kg

Outrigger Spread Front:
20’10” / 6,3 m


View Product Details
BT1870_featured

1870 BoomTruck

Lifting Capacity:
36,000 lbs / 16 329 kg

Maximum Vertical Reach:
120' / 36,6 m

Boom Length:
70’ / 21,3 m

Winch Bare Drum Pull:
12,800 lbs / 5806 kg

Overall Height:
12'11" / 3,9 m

Operator Controls:
Dual Standup

Unit Weight (Bare):
16,235 lbs / 7364 kg

Outrigger Spread Front:
20’10” / 6,3 m


View Product Details
BT1870CP_featured

1870CP BoomTruck

Lifting Capacity:
36,000 lbs / 16 329 kg

Maximum Vertical Reach:
120' / 36,6 m

Boom Length:
70’ / 21,3 m

Winch Bare Drum Pull:
12,800 lbs / 5806 kg

Overall Height:
12'10" / 3,9 m

Operator Controls:
Command Post

Unit Weight (Bare):
16,235 lbs / 7364 kg

Outrigger Spread Front:
17’6” / 5,3 m


View Product Details
1881TM Truss Crane

1881TM BoomTruck

Lifting Capacity:
36,000 lbs / 16 329 kg

Maximum Vertical Reach:
121' / 36,9 m

Boom Length:
81 ’/ 24,7 m

Winch Bare Drum Pull:
12,800 lbs / 5806 kg

Overall Height:
13'8" / 4,1 m

Operator Controls:
Dual Standup

Unit Weight (Bare):
16,420 lbs / 7448 kg

Outrigger Spread Front:
20’10” / 6,3 m


View Product Details
BT18125_featured

18125 BoomTruck

Lifting Capacity:
36,000 lbs / 16 329 kg

Maximum Vertical Reach:
137' / 41,7 m

Boom Length:
125’ / 38,1 m

Winch Bare Drum Pull:
12,800 lbs / 5806 kg

Overall Height:
13'5" / 4,1 m

Operator Controls:
Rotating Standup

Unit Weight (Bare):
27,500 lbs / 12 474 kg

Outrigger Spread Front:
20' / 6,1 m


View Product Details
BT2651TM_featured

2651TM BoomTruck

Lifting Capacity:
52,000 lbs / 23 587 kg

Maximum Vertical Reach:
61' / 18,6 m

Boom Length:
51’ / 15,5 m

Winch Bare Drum Pull:
12,800 lbs / 5806 kg

Overall Height:
13'5" / 4 m

Operator Controls:
Dual Standup

Unit Weight (Bare):
22,000 lbs / 9979 kg

Outrigger Spread Front:
20’8” / 6,3 m


View Product Details
BT8533

2695 BoomTruck

Lifting Capacity:
52,000 lbs / 23 587 kg

Maximum Vertical Reach:
152' / 46,3 m

Boom Length:
95’ / 28,9 m

Winch Bare Drum Pull:
12,800 lbs / 5806 kg

Overall Height:
13'5" / 4,1 m

Operator Controls:
Dual Standup

Unit Weight (Bare):
24,920 lbs / 11 303 kg

Outrigger Spread Front:
20’10” / 6,3 m


View Product Details
Elliott 26 ton 2695 digger boom truck and crane truck

2695-D BoomTruck

Lifting Capacity:
52,000 lbs / 23 586 kg

Maximum Vertical Reach:
152' / 46,3 m

Boom Length:
95' / 29 m

Winch Bare Drum Pull:
12,800 lbs / 5806 kg

Overall Height:
13'6" / 4,1 m

Operator Controls:
Dual Standup

Unit Weight (Bare):
29,785 lbs / 13 510 kg

Outrigger Spread Front:
20'10” / 6,3 m


View Product Details
BT26105_featured

26105 BoomTruck

Lifting Capacity:
52,000 lbs / 23 587 kg

Maximum Vertical Reach:
162' / 49,4 m

Boom Length:
105’ / 32 m

Winch Bare Drum Pull:
12,800 lbs / 5806 kg

Overall Height:
13'5" / 4,1 m

Operator Controls:
Dual Standup

Unit Weight (Bare):
26,040 lbs / 11 811 kg

Outrigger Spread Front:
20’10” / 6,3 m


View Product Details
BT26105F_Digger_featured

26105-D BoomTruck

Lifting Capacity:
52,000 lbs / 23 587 kg

Maximum Vertical Reach:
162' / 49,3 m

Boom Length:
105’ / 32 m

Winch Bare Drum Pull:
12,800 lbs / 5806 kg

Overall Height:
13'6" / 4,1 m

Operator Controls:
Dual Standup

Unit Weight (Bare):
29,785 lbs / 13 510 kg

Outrigger Spread Front:
20'10” / 6,3 m


View Product Details
BT3095_Elliott 3095F BoomTruck

3095F BoomTruck

Lifting Capacity:
60,000 lbs / 27 216 kg

Maximum Vertical Reach:
148' / 45,1 m

Boom Length:
95’ / 29 m

Winch Bare Drum Pull:
12,800 lbs / 5806 kg

Overall Height:
13'5" / 4,1 m

Operator Controls:
Rotating Standup

Unit Weight (Bare):
27,750 lbs / 12 587 kg

Outrigger Spread Front:
20' / 6 m


View Product Details
Elliott 30 ton 3095 digger utility boom truck and crane truck

3095R BoomTruck

Lifting Capacity:
60,000 lbs / 27 215 kg

Maximum Vertical Reach:
148' / 45,1 m

Boom Length:
95’ / 29 m

Winch Bare Drum Pull:
12,800 lbs / 5806 kg

Overall Height:
13'6" / 4,1 m

Operator Controls:
Rotating Standup or Cab

Unit Weight (Bare):
27,750 lbs / 12 587 kg

Outrigger Spread Front:
20' / 6 m


View Product Details
BT30105_featured

30105F BoomTruck

Lifting Capacity:
60,000 lbs / 27 216 kg

Maximum Vertical Reach:
162' / 49 m

Boom Length:
105’ / 32 m

Winch Bare Drum Pull:
12,800 lbs / 5806 kg

Overall Height:
13' / 4 m

Operator Controls:
Rotating Standup

Unit Weight (Bare):
28,160 lbs / 12 733 kg

Outrigger Spread Front:
20' / 6 m


View Product Details
Elliott 30 ton digger track vehicle boom truck and crane

30105-D BoomTruck

Lifting Capacity:
60,000 lbs / 27 216 kg

Maximum Vertical Reach:
162' / 49 m

Boom Length:
105’ / 32 m

Winch Bare Drum Pull:
12,800 lbs / 5806 kg

Overall Height:
13' / 4 m

Operator Controls:
Rotating Standup or Cab

Unit Weight (Bare):
29,785 lbs / 13 510 kg

Outrigger Spread Front:
20' / 6 m


View Product Details
Elliott 30 ton wireline crane boom truck and oilfield crane

30105R BoomTruck

Lifting Capacity:
60,000 lbs / 27 216 kg

Maximum Vertical Reach:
162' / 49 m

Boom Length:
105’ / 32 m

Winch Bare Drum Pull:
12,800 lbs / 5806 kg

Overall Height:
13'5" / 4 m

Operator Controls:
Rotating Standup or Cab

Unit Weight (Bare):
28,160 lbs / 12 733 kg

Outrigger Spread Front:
20' / 6 m


View Product Details
Elliott 32 ton 32117 boom truck and crane truck

32117F BoomTruck

Lifting Capacity:
64,000 lbs / 29 030 kg

Maximum Vertical Reach:
153' / 46,6 m

Boom Length:
117’ / 35,6 m

Winch Bare Drum Pull:
12,800 lbs / 5806 kg

Overall Height:
13'5" / 4,1 m

Operator Controls:
Rotating Standup

Unit Weight (Bare):
30,800 lbs / 13 971 kg

Outrigger Spread Front:
20' / 6 m


View Product Details
Elliott 32117 boom truck and crane truck 32 tons

32117R BoomTruck

Lifting Capacity:
64,000 lbs / 29 030 kg

Maximum Vertical Reach:
153' / 46,6 m

Boom Length:
117’ / 35,6 m

Winch Bare Drum Pull:
12,800 lbs / 5806 kg

Overall Height:
13'5" / 4,1 m

Operator Controls:
Rotating Standup

Unit Weight (Bare):
30,800 lbs / 13 971 kg

Outrigger Spread Front:
20' / 6 m


View Product Details
BT34127_featured

34127 BoomTruck

Lifting Capacity:
68,000 lbs / 30 844 kg

Maximum Vertical Reach:
186' / 57 m

Boom Length:
127’ / 39 m

Winch Bare Drum Pull:
12,800 lbs / 5806 kg

Overall Height:
12'6" / 3,8 m

Operator Controls:
Rotating Seated Crane Cabin

Unit Weight (Bare):
35,300 lbs / 16 012 kg

Outrigger Spread Front:
22'4” / 6,8 m


View Product Details
BT36127F_featured

36127F BoomTruck

Lifting Capacity:
72,000 lbs / 32 659 kg

Maximum Vertical Reach:
186' / 57 m

Boom Length:
127’ / 39 m

Winch Bare Drum Pull:
12,800 lbs / 5806 kg

Overall Height:
12'11" / 3,9 m

Operator Controls:
Rotating Standup or Cab

Unit Weight (Bare):
33,585 lbs / 15 234 kg

Outrigger Spread Front:
21'2” / 6,4 m


View Product Details
BT36127R_featured

36127R BoomTruck

Lifting Capacity:
72,000 lbs / 32 659 kg

Maximum Vertical Reach:
186' / 56,7 m

Boom Length:
127’ / 39 m

Winch Bare Drum Pull:
12,800 lbs / 5806 kg

Overall Height:
12'10" / 3,9 m

Operator Controls:
Rotating Standup or Cab

Unit Weight (Bare):
33,585 lbs / 15 234 kg

Outrigger Spread Front:
21'2” / 6,4 m


View Product Details
BT40105_featured

40105 BoomTruck

Lifting Capacity:
80,000 lbs / 36 287 kg

Maximum Vertical Reach:
164' / 50 m

Boom Length:
105’ / 32 m

Winch Bare Drum Pull:
15,000 lbs / 6804 kg

Overall Height:
13'2" / 4 m

Operator Controls:
Enclosed Cab

Unit Weight (Bare):
38,200 lbs / 17 327 kg

Outrigger Spread Front:
26'2” / 8 m


View Product Details
BT40142_featured

40142 BoomTruck

Lifting Capacity:
80,000 lbs / 36 287 kg

Maximum Vertical Reach:
207' / 63,1 m

Boom Length:
142’ / 43,3 m

Winch Bare Drum Pull:
15,000 lbs / 6804 kg

Overall Height:
12'10" / 3,9 m

Operator Controls:
Enclosed Cab

Unit Weight (Bare):
40,300 lbs / 18 280 kg

Outrigger Spread Front:
21'2” / 6,4 m


View Product Details
BT45127_featured

45127 BoomTruck

Lifting Capacity:
90,000 lbs / 40 823 kg

Maximum Vertical Reach:
192' / 58,5 m

Boom Length:
127’ / 38,7 m

Winch Bare Drum Pull:
15,000 lbs / 6804 kg

Overall Height:
13'2" / 4 m

Operator Controls:
Enclosed Cab

Unit Weight (Bare):
43,000 lbs / 19 504 kg

Outrigger Spread Front:
21'2” / 6,4 m


View Product Details
BT45142_featured

45142 BoomTruck

Lifting Capacity:
90,000 lbs / 40 823 kg

Maximum Vertical Reach:
207' / 63,1 m

Boom Length:
142’ / 43,3 m

Winch Bare Drum Pull:
15,000 lbs / 6804 kg

Overall Height:
12'10" / 3,9 m

Operator Controls:
Enclosed Cab

Unit Weight (Bare):
43,800 lbs / 19 867 kg

Outrigger Spread Front:
21'2” / 6,4 m


View Product Details
BT50105_featured

50105 BoomTruck

Lifting Capacity:
100,000 lbs / 45 359 kg

Maximum Vertical Reach:
164' / 50 m

Boom Length:
105’ / 32 m

Winch Bare Drum Pull:
15,000 lbs / 6804 kg

Overall Height:
13'2" / 4 m

Operator Controls:
Enclosed Cab

Unit Weight (Bare):
38,200 lbs / 17 327 kg

Outrigger Spread Front:
26'2” / 8 m


View Product Details
2308-1

L36R HiReach #2308

Working Height:
41' / 12,5 m

Lifting Capacity:
1,000 lbs

Platform Capacity:
350 lbs / 159 kg

Platform Type:
End Hung

Powered Boom Sections:
2


View Product Details
IMG_1023

L40R HiReach #4979

Working Height:
45'

Platform Capacity:
500 lbs

Platform Type:
EZR

Jib Winch Capacity:
500 lbs

Powered Boom Sections:
2


View Product Details
L40R 5343 2

L40R HiReach #5343

Working Height:
45'

Platform Capacity:
500 lbs

Platform Type:
End Hung

Jib Winch Capacity:
500 lbs


View Product Details
2905_usedffeature

L55R HiReach #2905

Working Height:
57

Lifting Capacity:
5,900 lbs

Working Side Reach:
51

Platform Capacity:
500 lbs

Platform Type:
EZR

Powered Boom Sections:
3


View Product Details
5770-2

L60R HiReach #5770

Working Height:
62'

Lifting Capacity:
5,900 lbs

Working Side Reach:
56'

Platform Capacity:
500 lbs

Platform Type:
EZR

Jib Winch Capacity:
500 lbs

Powered Boom Sections:
3


View Product Details
v60-194740

V60F HiReach #194740

Working Height:
63'

Platform Capacity:
500 lbs

Jib Winch Capacity:
500 lbs


View Product Details
v60-2-194741

V60F HiReach #194741

Working Height:
63'

Platform Capacity:
500 lbs

Platform Type:
Top Mount

Jib Winch Capacity:
500 lbs


View Product Details
2202-1

H70R HiReach #2202

Working Height:
70'

Lifting Capacity:
5,900 lbs

Platform Capacity:
500 lbs

Platform Type:
EZR


View Product Details
IMG_3617

H70R HiReach #2384

Working Height:
70' / 21,3 m


View Product Details
4524 3

G85R HiReach #4524

Working Height:
85'

Lifting Capacity:
5,900 lbs

Working Side Reach:
61'

Platform Capacity:
500 lbs

Platform Type:
EZR

Jib Winch Capacity:
500 lb


View Product Details
2356-3

G85F HiReach #2356

Working Height:
90' / 27,4 m

Working Side Reach:
58' / 17,7 m

Platform Capacity:
600 lbs / 272 kg

Platform Type:
Top Mount


View Product Details
2488-2

G85F HiReach #2488

Working Height:
90'

Lifting Capacity:
2,000 lbs

Working Side Reach:
61'

Platform Capacity:
600 lbs

Platform Type:
Top Mount


View Product Details
30105F 5554 1

30105F BoomTruck #5554

Lifting Capacity:
60,000 lbs

Boom Length:
105'

Powered Boom Sections:
4

Winch Bare Drum Pull:
12,800 lbs

Operator Controls:
Standup Cab

Outrigger Spread Front:
20'


View Product Details
